Nominal distance from P.M.I

mm

6

Nominal force

kN

4500

Stroke of the ram

mm

400

Ram adjustment

mm

100

Speed in continuous

stroke/1’

20÷35

Max. speed

rpm

50

N°of stroke in single stroke max.

stroke/1’

18

Shut height (C.B.R.A.)

mm

775

Dimension of the bolster plate

mm

1050x1050

Power of the cushion

kN

900

Stroke of the cushion

mm

50÷140

Cushion adjustment

mm

90

Power of the main motor

kW

75

Weight approx.

kg

41000
